Technical Specifications:

Vacuum Controller                       : Microcontroller Based

Material of Construction            : Stainless Steel

Maximum Vacuum Level               : Better than 650 mm of Hg

Vacuum Setting            : Vacuum can stabilize for a set value from:

  Less than 400 mmHg   : ± 10 mmHg within 30 seconds

  Above 400 mmHg        : ± 5 mmHg within 30 seconds

Vacuum Hold Time                      : Variable from 1 sec. to 99 min

Vacuum Release Time                  : Variable from 1 sec. to 5 min

Number of Sample                       : 1 to 99

Vacuum Initial Delay Time             : Variable from 1to 60 second to achieve 100 mm of Hg

                                                  (Run will be aborted if 100 mm of Hg will not reach in 60 second)

Time                                         : Real time clock

Display                                      : 20 x 4 Line Alphanumeric Backlit LCD

Keypad                                      : Membrane waterproof polycarbonate soft touch keypad compliance to UL/ROHS

Vacuum Gauge                           : Digital Display by user friendly touch pad

Auto Release of Vacuum               : Yes – after completion of Vacuum Time

Pharmacopeia Complies                : As per USP, IP, Ph. Eur.

Method                                      : 40 methods with View, Print & Delete facility

Calibration                                 : with NABL Certified Standard Digital Vacuum Gauge

Calibration Data Storage               : Non-Volatile Memory which can store, print & view calibration date & time, company

  name, User name, set and actual reading of Vacuum, calibration done by, instrument

  serial number, instrument ID, model number etc.

Searching of data                        : with record number, batch number, Date and by scrolling

Report Formation                        : As per GLP Compliance

Analysis Data Storage                   : More than 1500 analysis data can be stored with company name, analysis date &

  time, record number, batch number / ID, sample name, user name, assigned method

  number, numbers of samples, set vacuum, vacuum hold time, vacuum release time,

  vacuum calibration date, analysis done on model number, serial number, instrument ID

  etc. Secondly, analysis data can print directly from analysis mode without saving

  analysis data in instrument.

21 CFR Part-11 Compliance       : ● In-built with system

  ● 1 Admin and 7 users with different Login ID & Password.

  ● Audit trail can store more than 5000 lines in system itself.

  ● Audit trail includes action taken, date & time, action taken by whom.

  ● Audit trail can be transfer to PC through ANALABsafe software and

     can print on 40 / 80 column dot matrix printer for record.

  ● Once Audit trail transfer to the PC or Printer, automatically system

     will delete Audit trail records and before final deleting, the system

     will give warning twice.

Printer Interface                          : Centronics Parallel Port / Serial (RS-232 C) Port

PC Interface                               : USB Type - B

Printer                                       : 40 / 80 Column Dot Matrix Printer (Printer have to procure optionally)

PC Connectivity                           : By USB Interface Cable with Driver, ANALABsafe software to transfer Analysis data in

  GLP formate, Calibration data and Audit trail from Instrument to PC in non editable

  formate and is password protected.

Power Supply                              : 230VAC ± 10%, 50Hz
