Introduction

EIE Stability Chambers are designed as per ICH Guidelines for precise monitoring of temperature and humidity conditions required for long term, intermediate & accelerated stability studies at chemical, pharmaceutical, agrochemical manufacturing facilities. These chambers are manufactured to comply with GMP requirements.

Salient Features

• CE Certified

• Double wall construction

• Fulfills storage conditions of 25° C - 60% RH, 40° C - 75% RH, 30° C - 65% RH, 25° C - 40% RH, 30° C - 35% RH

• Designed for testing product shelf – life, Packing and Electronic test.

• Specially designed to meet ICH, WHO & USFDA requirements.

• Full size polycarbonate sheet inner door to inspect samples without affecting the control parameters.

• Electrical wiring as per CE Compliances

• Illuminated working area

• User friendly and tactfully designed chamber door and locking mechanism

• Forced air circulation for uniform temperature and RH Distribution

• Ensures smooth air-flow pattern to improve the Temp & Humidity distribution across the chamber

• U-Shaped tubular heaters as heating element.

• Unit mounted on castor wheels for easy movement.

• Uniformity module with 4 + 4 RH & Temp Sensors (Optional)

• Password protected door access and monitoring (Optional)

• GSM module for SMS Alert (Optional)

• Serial port for PC interface with 21-CFR Compliant software (Optional software)

• Standby Humidity control system and Standby refrigeration system (Optional)

Insulation

70mm polyurethane insulation (PUF)/ fiberboard to ensure thermal loss

Humidity System

Non-condensing type Steam injection system & reservoir tank with water level arrangement with indicator.

Cooling System

Hermetically sealed compressor, which is CFC free and eco-friendly, utilizes the refrigerant (R-134A gas) to maintain chamber temperature within specified range.

Technical Specifications

• Temperature Range: 20 °C to 60 °C
• Humidity Accuracy: ± 2% RH
• Temperature Accuracy: ± 0.2 °C
• Humidity Uniformity: ± 3% RH
• Temperature Uniformity: ± 1°C
• Supply: 230V Ac, 50 Hz, Single Phase
• Humidity Range: 40% RH to 95% RH

Salient Features

• 21-CFR Compliance software with PC Communication

• Highly advanced HMI & PLC Control system

• GSM Alert through SIM Card

• Data logger with 4 temperature + 4 Humidity sensors

• Spare RH Sensor for validation purpose

• Spare PT-100 Sensor for validation purpose

• Standby Humidity System

• Standby Refrigeration System

• Biometrics Magnetic Door Access for Secured Door opening with software to maintain log

• On-Site Validation (mapping) for 24 hours on Empty, Half and Full load condition
