SINGLE SIDE OR DOUBLE SIDE SIMULTANEOUSLY ON ANY SHAPE & SIZE CONTAINERS
Two label dispensers operates independently which allows different size of label application on either side.
DIGITAL SERVO TECHNOLOGY
Machine can be opted with servo technology in order to get highest accuracy for label placement.
TOOL LESS OPERATION
Unique spring loaded twin worm system virtually eliminates the use of any tools making it tool-less operation.
SAFETY OF THE CONTAINER
Spring action feed worm / feed screw ensures high safety to containers in case of toppling down does not damage.
3 AXIS LABEL DISPENSER
3 Axis label dispensers allows any degree of label dispensing possible for any shape & bottle.
PRODUCT HANDLING
Apart from feed screw system machine can be supplied with belt orientation system for multi product handling without change part.
NOTCH ORIENTATION
Very unique notch orientation system for registered/fix position of label is also possible.
SPEED
SPEED UPTO 100-200-300 CONTAINERS / MIN.
ROUND BOTTLE ATTACHMENT
Round bottle attachment can also be provided on same machine to make it a combo machine which can do flat as well as round labelling.
ONE TOUCH SPEED SYNCHRONIZATION
Complete machine is synchronized with one touch speed for ease of use.
SAFTEY
Machine comes with Safety Cabinet With Acrylic Covers & Imported Aluminium Profile With Interlocking. In case of Door open, Machine will be Stop.
Speed | 100/200/300 BPM |
Label Length | 8 to 300 mm. |
Label Height | 95 / 165 / 210 mm. |
Dispenser Motor | Stepper/Servo |
Stop Tolerance | +/- 0.5 to 0.75 mm (servo) |
+/- 0.75 to 1.00 mm (stepper) | |
Roll Dia. | 350 mm std. & 550 mm (optional) |
Product Feeding & Orientation | Side belt conveyor with diff. speed Nylon Twin-Feed Worm Assy |
Flat / Oval Bottle (Change Part as per Container) | |
Product Holding | Specially designed spring loaded/cushion type top belt. |
HMI | Feather touch keypad (std.) Touch HMI or Ind. PC (optional) |
